Marshall-Tufflex has introduced a range of power and data Desk Modules to complement its Underfloor to Desk range.
The high strength, fire retardant polycarbonate moulded modules are ideal for under desk mounting, incorporating twin 5Amp USB points that charge up to five times faster than standard PC ports.
The pre-wired, pre-tested power modules can be used individually or linked to serve multiple workstations using Wieland GST18/3 connectors. With additional circuit protection via aluminium RCBO units there is the ability to connect direct from powertrack up to single or multiple configurations, delivering a complete underfloor to desk system.
The new Desk Modules offer maximum installation speed and flexibility:
- Feed directly from an underfloor busbar through a floor grommet to an RCBO unit to then feed single or multiple modules as required
- Feed from wall trunking, floor boxes, grommets or PowerPoles
- RJ45 data sockets in Cat 5e, Cat 6 or blank configuration options
The unswitched individually fused 3.15Amp or 5Amp units have been designed to withstand the rigours of the commercial environment. They are available in 2 and 4 gang options and comply with BS 6396 for Electrical Systems in Office Furniture when powered from a plug socket outlet and with BS 7671 when powered from a power distribution network.
